FAG taper roller bearing with 100% original guaranteed 32228-A

  • FAG taper roller bearing with 100% original guaranteed 32228-A
  • FAG taper roller bearing with 100% original guaranteed 32228-A
  • FAG taper roller bearing with 100% original guaranteed 32228-A
  • FAG taper roller bearing with 100% original guaranteed 32228-A
Place of Origin Germany
Brand Name FAG
Model Number 32228-A
Minimum Order Quantity 1 set
Price ASK
Packaging Details Original
Delivery Time 1-3 working days
Payment Terms T/T;Western Union;Paypal

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Leave a Message
Product Description

FAG taper roller bearing 32228-A

d 140  mm
D 250  mm
T 71,75  mm

a 60  mm    ≈
B 68  mm
C 58  mm
Ca min 8  mm
Cb min 13,5  mm
Da max 236  mm
Da min 210  mm
Db min 238  mm
d1 193,5  mm    ≈
da max 159  mm
db min 154  mm
r1, 2 min 4  mm
r3, 4 min 3  mm
ra max 4  mm
rb max 3  mm

m 14,5  kg    ≈ Mass
Cr 640000  N    Basic dynamic load rating, radial
C0r 990000  N    Basic static load rating, radial
e 0,43
Y 1,38
Y0 0,76
Cur 120000  N    Fatigue limit load, radial
nG 2700  1/min    Limiting speed
nB 1760  1/min    Reference speed
  T4FD140    Comparative designation to DIN ISO 355
