PLC59-5 spherical roller bearing for cement mixer gearboxes
|
Bearing Model |
PLC59-5 |
|
Brand |
FAG |
|
Bearing Category |
Spherical Roller Bearing |
|
Origin of Country |
Germany |
|
d |
100 mm |
|
D |
180 mm |
|
B |
82 mm |
|
Dynamic Load |
310 kN |
|
Static Load |
550 kN |
|
Mass |
10.3 kg |
|
Figure |
1 |
The following bearings are designed for use in mobile cement mixer gearboxes. The bearings are mounted onto the main shaft of the gearbox and are offered in three basic designs: PLC 58-6, PLC 59-5, and PLC 59-10, all have awider outer ring, increasing the self-aligning ability of the bearing. These bearings are produced within ABEC 1 tolerance and have a C0 radial clearance.
The PLC 59-5 has a two-piece brass cage, which allows a higher operating temperature than other plastic cage
designs. The brass cage also offers complete compatibility with all synthetic lubricants.
The PLC 59-10 also has a two-piece brass cage and offers all the same design advantages as the PLC 59-5. This
bearing also has a high capacity design, which increases the dynamic and static load ratings. Both PLC 59-5 and
PLC 59-10 have a two-piece split outer ring, which allows for maximum rollers and a narrower inner ring.
The PLC 58-6 has a polyamide cage, which allows the bearing to be assembled so that the outer ring does not have
to be split into two pieces.
