FAG taper roller bearing with 100% original guaranteed 32320-A

FAG taper roller bearing with 100% original guaranteed 32320-A

China FAG taper roller bearing with 100% original guaranteed 32320-A supplier
FAG taper roller bearing with 100% original guaranteed 32320-A supplier FAG taper roller bearing with 100% original guaranteed 32320-A supplier FAG taper roller bearing with 100% original guaranteed 32320-A supplier

Large Image :  FAG taper roller bearing with 100% original guaranteed 32320-A

Product Details:

Place of Origin: Germany
Brand Name: FAG
Model Number: 32320-A

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: ASK
Packaging Details: Original
Delivery Time: 1-3 working days
Payment Terms: T/T;Western Union;Paypal
Contact Now
Detailed Product Description

FAG taper roller bearing 32320-A

d 100  mm
D 215  mm
T 77,5  mm

a 53  mm
B 73  mm
C 60  mm
Ca min 8  mm
Cb min 17,5  mm
Da max 201  mm
Da min 177  mm
Db min 200  mm
d1 152  mm
da max 123  mm
db min 114  mm
r1, 2 min 4  mm
r3, 4 min 3  mm
ra max 4  mm
rb max 3  mm

m 12,9  kg    ≈ Mass
Cr 610000  N    Basic dynamic load rating, radial
C0r 840000  N    Basic static load rating, radial
e 0,35
Y 1,74
Y0 0,96
Cur 94000  N    Fatigue limit load, radial
nG 3250  1/min    Limiting speed
nB 2360  1/min    Reference speed
  T2GD100    Comparative designation to DIN ISO 355

FAG taper roller bearing with 100% original guaranteed 32320-A

FAG taper roller bearing with 100% original guaranteed 32320-A
