INA cylindrical roller bearings with 100% original guaranteed SL045032-PP-2NR

  • INA cylindrical roller bearings with 100% original guaranteed SL045032-PP-2NR
  • INA cylindrical roller bearings with 100% original guaranteed SL045032-PP-2NR
  • INA cylindrical roller bearings with 100% original guaranteed SL045032-PP-2NR
  • INA cylindrical roller bearings with 100% original guaranteed SL045032-PP-2NR
Place of Origin Germany
Brand Name INA
Model Number SL045032-PP-2NR
Minimum Order Quantity 1 set
Price ASK
Packaging Details Original
Delivery Time 1-3 working days
Payment Terms T/T;Western Union;Paypal

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Leave a Message
Product Description

INA full complement cylindrical roller bearing SL045032-PP-2NR

d 160  mm
D 240  mm
B 109  mm

  30  °    Chamfer angle
C 108  mm
C1 95,2  mm    Tolerance: +0,2/0
Ca1 89  mm    Mounting dimension for snap ring WRE (not included in delivery)
Tolerance: 0/-0,2
Ca2 85  mm    Mounting dimension for retaining ring to DIN 471 (not included in delivery)
Tolerance: 0/-0,2
D1 236  mm    Tolerance: +0,2/0
d1 189  mm
d2 207  mm
d3 260  mm    Outside diameter of snap ring WRE
m 5,2  mm
rmin 0,6  mm
t 2  mm
X 89  mm    Distance between rolling elements

m 16,6  kg    Mass
Cr 740000  N    Basic dynamic load rating, radial
C0r 1360000  N    Basic static load rating, radial
Cur 173000  N    Fatigue limit load, radial
nG Fett 790  1/min    Limiting speed for grease lubrication
  WRE240    Designation for snap ring WRE (not included in delivery)
  240X5    Designation for retaining ring to DIN 471 (not included in delivery)
